92101-17010 Head Light for HYUNDAI Matrix 2001-2002 Left
Primary OE reference: 92101-17010
Cross-reference number 1: 92101-17010
Product type: Head Light Assembly
Applicable vehicle: HYUNDAI Matrix 2001-2002
Installation position: Left front headlamp position
Brand: HYUNDAI
Model: Matrix
Vehicle year: 2001-2002
Lighting configuration: Match the photographed optical configuration
Housing comparison: Lay the replacement beside the removed unit and compare overall depth, edge returns, vent locations and rear-cover clearance.
Optical system: Inspect reflector colour, projector presence and any decorative internal trim before approving a left/right pair for one vehicle.
Electrical interface: Review terminal count, plug orientation and the location of removable caps before transferring bulbs or reusable electronics.
Mounting points: Verify that repaired body supports are square before judging lamp fit, because collision distortion can imitate a part mismatch.
Installation guidance: Keep wiring clear of hot or moving components, then test low beam, high beam, indicator and daytime lighting where applicable.
Wholesale packing: Left and right units should be labelled separately, and internal supports should keep the lamp from moving inside the export carton.
Application-specific focus: For the left HYUNDAI Matrix application with match the photographed optical configuration, establish whether the original lighting system uses a reflector, projector, halogen bulb, xenon burner or integrated led light source.
Head Light Assembly Overview
The listed unit is designed for the stated vehicle position and should be matched to the removed headlamp before installation. It is catalogued under OE reference 92101-17010 for HYUNDAI Matrix 2001-2002, with the left position identified in the source record.
The photographed lens, internal optical layout, rear casing and attachment points should be reviewed as one system. A close-looking lamp from another trim or market can differ behind the body opening.
Lighting Function and Optical Configuration
Review reflector colour, projector presence and any decorative internal trim before approving a left/right pair for one vehicle.
For the Matrix application, verify the lighting package fitted to the vehicle. Standard, projector, xenon and LED versions can use non-matching internal modules, beam controls and daytime-light signatures.
Vehicle Fitment and Body Interface
Confirm that the headlamp sits naturally in the body opening and follows the bonnet, grille and fender lines without forced alignment.
Confirm that repaired body supports are square before judging lamp fit, because collision distortion can imitate a part mismatch.
Connector and Control Hardware
The electrical interface should seat without modification, and the harness must reach the connection without tension or contact with sharp edges.
Confirm the supply scope shown in the product photographs. Bulbs, rear caps, levelling motors, ballasts, LED drivers and auxiliary brackets may vary between versions and should be checked separately.
Installation and Beam Alignment
Complete a no-force trial fit first; once the panel gaps are even, secure the unit and adjust the beam to workshop specifications.
A qualified workshop should examine surrounding supports for damage, complete the electrical tests and set the headlamp beam according to local requirements after installation.
Automotive Lighting Product Specifications
| Product type | Head Light Assembly |
|---|---|
| Primary OE reference | 92101-17010 |
| Cross-reference numbers | 92101-17010 |
| Internal item code | HY04001-023 |
| Vehicle brand | HYUNDAI |
| Vehicle model | Matrix |
| Model year | 2001-2002 |
| Installation position | Left front |
| Lighting configuration | Match the photographed optical configuration |
Wholesale Supply and Protective Packing
For wholesale supply, the lens should be isolated from carton pressure while the rear shell, adjusters and projecting mounting tabs are supported.
When requesting a quotation, supply the vehicle application, production period, required side, lighting technology, quantity and destination. Original-lamp photographs are useful when several versions exist.
Application-Specific Comparison Notes
For this left HYUNDAI Matrix headlamp, the correspond to the photographed optical configuration specification should be assessed together with the 2001-2002 body application. Lay the replacement beside the removed unit and review overall depth, edge returns, vent locations and rear-cover clearance.
The left Matrix lighting package should remain the reference during electrical review. Compare every plug and socket with the original unit and establish whether the levelling motor, ballast or LED driver is included or transferred.
When fitting the HYUNDAI Matrix unit at the left front position, preserve even body gaps and the intended beam orientation. Keep wiring clear of hot or moving components, then test low beam, high beam, indicator and daytime lighting where applicable.
Frequently Asked Questions
How can connector compatibility be reviewed?
Compare keying, terminal count, latch direction and wire exit, then determine any required ballast, driver or levelling motor.
Are bulbs and electronic modules included?
The included components are those photographed in the product photographs. Inspect bulbs, caps, motors, ballasts and LED modules separately.
What should be checked before installation?
For the Matrix, examine the vehicle supports, review every fixing point, verify the connector and complete a no-force trial fit.
How should headlamp fitment be confirmed?
For the left Matrix lamp, compare the body outline, mounting tabs, connector and lighting technology with the removed unit. Model year alone may not distinguish every trim.
Can a headlamp be chosen by appearance alone?
No. The left lamp must also correspond to the optical system, electrical interface, mounting features and market specification.
